Copper sheet
Corrosion-resistant metal sheet used for roofing, cladding and electrical work.
Request a quoteMeasurements
2000x1000Technical information
...
| WEIGHT - DIMENSIONS TABLE: Weight kg/unit | ||||||
|---|---|---|---|---|---|---|
| Thickness | 1400x700 | 2000x1000 | 3000x1000 | |||
...
| Sheets and strips for general applications | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| STANDARD: EN 1652 | ||||||||||
| Copper composition | ||||||||||
| Material designation | Composition (mass content) in % | Mass density (2) | ||||||||
| Symbol | Number | Element | Cu (1) | Bi | O | P | Pb | Other elements | g/cm³ Approx. | |
| Total | Exclusion of | |||||||||
| Minimum value (range) | |||||||
|---|---|---|---|---|---|---|---|
| Alloy | Tensile strength Rm (N/mm²) | Yield strength Rp0.2 (N/mm²) | Elongation A50 (%) | Elongation A5 (%) | Hardness HV | Conductivity (MS/m) | Conductivity IACS (%) |
| EN 1652 CU-ETP R290 | 290–360 | 250 | 0 | 0 | 90–110 | 57 | 98.3 |
| EN 1652 CU-ETP R220 | 220–260 | 0 | 33 | 0 | 40–65 | 58 | 100 |
| EN 1652 CU-ETP R240 | 240–300 | 169 | 0 | 0 | 65–95 | 57 | 98.3 |
